250amp Power Distro Rack

Power Distribution Rack

Schneider 20A/1P *6

Individual Breaker

Schneider 20A/1P *6

Individual Breaker

50a CS6369 240v Outlet *4

400A/208V Camlock out

400A/208V Camlock in

V/120V (L1,L2,N/G)

- HZ

LED OFF/ON

Schneider 50A/2P *4

Individual Breaker

Schneider 250A/3P

12U RACK

16 WAY SHOCK

PROOF

L5-20 120V *6 out

L5-20 120V *6 out

PE

(green)

Female

N (white)

Female

L1

(black) male

L2

(red) male

L3

(blue) male
